TinkerLab | Audiovisualiser - Week 3

March 27 - 28, 2023

On March 27, we focused on troubleshooting by resoldering broken connections in our project. This step was crucial to ensure the proper functioning of the circuit.

The next day, we dedicated our efforts to setting up and testing the Audiovisualiser code. Initially, the code produced a vertical LED output, which was not the desired outcome. However, with the assistance of ChatGPT, we managed to fix the code, resulting in a successful horizontal LED output.

Additionally, we conducted experiments with the power supply. Fortunately, our efforts proved successful as we discovered that the Audiovisualiser circuit could be powered using a 10,000mAh power bank. This finding provided a reliable and portable power solution for our project.

‍
