TinkerLab | Polishing

May 23 - 30, 2023

Over the course of several days, we continued to make minor changes and fixes. On May 23, we focused on finalizing the switch mode button and sanding the sides of the board. The next day, we successfully mounted the forex sheet onto the MDF using foam, securely fastening the button matrix in place. We inserted foam and unused PVC pipes between the forex sheet and MDF board, and glued the board sides for further stability. To ensure proper organization, we diligently labeled the jumper wires, designating each one to its respective Arduino pin.

Finally, on May 30, we addressed a broken power supply wire connection by re-soldering it and securing it with hot glue. As a finishing touch, we adorned the sides with black vinyl stickers, to cover up the inner workings of the board.

‍

Previous Entry

Next Entry

5/31/23

The Deeno board was showcased on campus, receiving positive feedback. Minor bugs were addressed for completion.

5/30/23

Finalized switch mode button, sanded board sides. Mounted forex sheet, glued board sides, labeled jumper wires. Resoldered power supply wire, added black vinyl sticker.
